About // 470V Van Trailer

470V Van Trailer - 12ft x 6ft x 6ft 6" Largest 2600kg Van Trailer

Trailer Specification

  • Largest 2600kg van trailer, Avon-ride/soft-ride, twin galvanised axles, braked trailer
  • Heavy-duty galvanised steel chassis
  • Internal steel frame with strong lashing rings above floor level
  • Sides are protected inside by steel tophat load securing rails
  • Trailer is panelled with high gloss glass fibre plywood laminate one-piece side sheets
  • 18mm no-slip phenol coated plywood floor with a translucent glass fibre roof
  • Aerodynamic front is glass fibre with an 18mm ply internal bulkhead, with storage pockets
  • Ingenious mirror enables alignment of vehicle tow ball and trailer hitch to be seen by the driver during coupling, eliminating misalignment and damaged bumpers
  • Auto-reversing over-run brakes, with cast coupling and integral jockey wheel
  • Mudguards are sealed to the body and have special damage-resistant end mouldings
  • Rear door can either be the standard roof-mounted aluminium roller shutter or optional double side hinged van door with a container type lock or a heavy-duty spring-assisted full height ramp (allow approximately 50kg increase in unladen weight)
  • Rear lamps within one unit, mounted on steel brackets, wired with a waterproof junction box
  • Spare wheel and carrier

Optional Extras

  • Punched track and load securing pole
  • Increased headroom 150mm or 300mm (per 300mm length)
  • Rear loading stands (per pair)
  • 12v interior light
  • Spring-assisted loading ramp replacing roller shutter doors
  • Alloy tread plate floor (per square foot)
  • Side personnel door
  • Double van doors replacing roller shutter doors
Pricing
Specifications

Pricing

PartPrice
470V Van Trailer (includes VAT)£7380.00
Increased Headroom 150mm or 300mm (Per 300mm length)£30.00
Rear Loading Stands (per pair)£48.00
12v Interior Light£60.00
Spring Assisted Loading Ramp Replacing Roller Shutter Doors£264.00
Alloy Tread Plate Floor (per square foot)£7.20
Side Personnel Door £300.00
Double Van Doors Replacing Roller Shutter Doors£264.00

Specifications

Trailer470V Van
Gross Weight2600kg
Unladen Weight730kg
Payload1870kg
Internal Length3560mm
Internal Width1770mm
Internal Height1880mm
Platform Height0mm
Overall Length4880mm
Overall Width2300mm
Overall Height2440mm
Register Your Interest

Gallery

Trailer Deliveries

Bateson Trailers - Manufacturers Delivery Charge - £130.00
